DISCRIPTION OF OPERATING SYSTEM 4-23
628O445A
WORK LIGHT (FRONT/REAR)
(1) Work Light (Front) Switch
(2) Work Light (Rear) Switch
(3) Work Lamp
To turn on, choose the switch marked
“front” or “rear” and move to the “ON”
position.
WARNING
Do not drive on the road with the
rear work lights turned on. It cre-
ates a hazard for other drivers
and may be illegal in some areas.
Use the hazard lights for road
travel.
628O448A
(1) Door Prop(LH,RH)
When operating the tractor with the doors
open, use the door prop to secure the
door. Do not leave the doors fully open
while driving the tractor.
628O446A
WIPER
(1) Wiper Switch (Front)
(2) Wiper Switch (Rear)
(3) Wiper, Front
1. To turn on, position the switch marked
(wiper) to the “ON” position.
2. Pressing the “ON” switch further will
momentarily activate the windshield
washer.
3. The tank for the washer fluid is lo-
cated on the left side behind the seat.
To Next Page
