9
PARTS LOCATION
BACK MIRROR BACK MIRROR
CHOKE LEVER
PASSING SWITCH
CLUTCH LEVER
HEADLIGHT
DIMMER SWITCH
WINKER SWITCH
HORN BUTTON FUEL TANK CAP
HEADLIGHT SWITCH
FRONT BRAKE FLUID
R E S E R V O I R
MAIN SWITCH
FRONT BRAKE LEVER
THROTTLE GRIP
STARTER BUTTON
FUEL GAUGE
T A C H O M E T E R
S P E E D O M E T E R
영문-메뉴얼작업󰼿󰼿2005.12.29󰼿4:58󰼿PM󰼿󰼿페이지9

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the DAELIM VS125 and is the answer not in the manual?

DAELIM VS125 Specifications

General IconGeneral
Displacement124.6 cc
Cooling SystemAir-Cooled
Fuel SystemCarburetor
Front SuspensionTelescopic Fork
Front BrakeDisc
Rear BrakeDrum
IgnitionCDI
Starting SystemElectric & Kick
