DAELIM VS125 - Air Cleaner Element; Idle Speed Adjustment

35
●If air cleaner element is
inadequately assembled, dust and
other foreign matters are
absorbed directly into the
element, inducing cylinder wear
or output deterioration and
adversely affecting engine
durability. Assemble correctly.
● When cleaning vehicle, be
careful not to allow water to get
into air cleaner. If water gets
inside air cl eaner, it causes
inefficient engine starting.
①Put vehicle in upright position on a flat
ground.
②Start engine and let it run idle for a few
minutes.
③Using the throttle stop screw, adjust
idling to prescribed level.
IDLING REVOLUTION: 1,400±100rpm
④Tighten up pilot screw and loose
backward 1¾to open.
⑤Operate throttle lever lightly and verify
there is no change in the number of idle
running. If there is a change, repeat the
process described in paragraph ③ and ④
IDLE SPEED ADJUSTMENT
A I R 󰼿 C L EANER
E󰼿L󰼿E󰼿M󰼿E󰼿N󰼿T
S ET 󰼿 S P R I N G
T󰼿H󰼿R󰼿O󰼿T󰼿T󰼿L󰼿E
S T OP 󰼿 SCRE W
