DAELIM VS125 User Manual

12
METER READING AND USAGE FUEL GAUGE
METERS
TACHOMETER
TR I P󰼿 M ETER󰼿RE S ET󰼿 K N O B
<SPEEDOMETER>
Indicates speed in km/h during travel.
Maintain legal speed limits to ensure safe
operation.
<ODOMETER>
Indicates total operating distance in km.
<TRIP METER>
Indicates travel distance from the point
the meter is reset to “0”. To reset meter,
turn the trip meter knob to the direction of
arrow.
Indicates amount of gasoline in fuel tank.
(The fuel gauge needle always indicates
gasoline level regardless of whether main
switch is in "OFF" position or in "ON"
position.) If needle is within "E" mark,
immediately fill gasoline. Balance at this
time is approxi-mately 1.0 litres.
Indicates engine revolutions. (rpm)
S󰼿P󰼿E󰼿E󰼿D󰼿O󰼿M󰼿E󰼿T󰼿E󰼿R
T R I P󰼿 M ETE R
O󰼿D󰼿O󰼿M󰼿E󰼿T󰼿E󰼿R
T󰼿A󰼿C󰼿H󰼿O󰼿M󰼿E󰼿T󰼿E󰼿R FUEL󰼿 G AU G E
DA NG ER󰼿Z ON E(RE D 󰼿Z O NE)
●Make sure, during travel, the tachometer
needle cannot be entered danger zone(red zone)
due to excessive engine running.
●Pay particular attention because idle engine
running or abrupt acceleraion in the 1st or 2nd
gear may cause the tachometer needle to be
in thedanger zone(red zone).
Danger zone means the engine revolution
limit and, if engine is run beyond this danger
limit, engine will be damaged.
영문-메뉴얼작업󰼿󰼿2005.12.29󰼿5:2󰼿PM󰼿󰼿페이지12

DAELIM VS125 Specifications

General

Displacement	124.6 cc
Cooling System	Air-Cooled
Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Ignition	CDI
Starting System	Electric & Kick
