4–36 CLIMATE CONTROL AND AUDIO SYSTEM
SPECIFICATIONS (EXCERPTS)
Power supply Direct current 14.4 V
Loudspeaker impedance 4 – 8 ohm (4 loudspeakers)
Output power 4 x 20 watts sine in accordance with DIN 45 324 at 14.4 V / 4 x 40 watts max. power
RADIO COMPONENT
Frequency range FM: 87.5 – 108.0 MHz
MW: 531 – 1602 kHz
LW: 153 – 279 kHz
Input sensitivity AM: 27 dBµV at 20 dB S/N
FM: 5 dBµV at 26 dB S/N
LW: 30 dBµV at 20 dB S/N
Signal-to-noise ratio FM/ AM: 55 dB
Stereo channel separation 26 dB
CASSETTE COMPONENT
Tape speed 4.76 cm/sec.
Wow and flutter < 0.35 %
Signal-to-noise ratio > 40 dB (Mech. deck),
> 50 dB with Dolby (Logic deck)
Cross talk > 40 dB
Frequency response 30 – 12,000 Hz
