SERVICE AND VEHICLE CARE 6–39
2. Rotate the front fog lamp bulb coun-
terclockwise and remove it.
3. Replace the bulb. See “BULB SPECI-
FICATIONS” in the index.
4. Connect the wiring harness connec-
tor to the front fog lamp bulb.
SIDE TURN SIGNAL LAMPS
Bulb replacement
1. Remove the side turn signal lamp as-
sembly by pulling it forward.
2. Rotate the bulb holder counterclock-
wise.
3. Remove the bulb from the lamp
housing by pulling the bulb straight
out of the holder.
4. Insert the proper replacement bulb in
the bulb holder by pushing in and ro-
tating the bulb holder clockwise. See
“BULB SPECIFICATIONS” in the in-
dex.
5. Push the side turn signal lamp assem-
bly back into its original position.
Bulb replacement (Hatchback)
1. Rotate the plastic cap counterclock-
wise and remove it
2. Release the spring that retains the
bulb.
3. Remove the bulb from the housing
and replace it
4. Install the plastic cap by rotating it
clockwise.
S3W6532A
