4–58 CLIMATE CONTROL AND AUDIO SYSTEM
SPECIFICATIONS (EXCERPTS)
Power supply Direct current 14.4 V
Loudspeaker impedance 4 – 8 ohm (4 loudspeakers)
Output power 4 x 20 watts sine in accordance with DIN 45 324 at 14.4 V / 4 x 40 watts max. power
CD CHANGER COMPONENT
Type and model Compact Disc Digital Audio
System
CD format 12 cm compact disc
Frequency response 20 – 20,000 Hz
Distortion factor < 0.1 %
Dynamic range > 80 dB
Signal-to-noise ratio > 80 dB
Channel separation > 70 dB
RADIO COMPONENT
Frequency range FM: 87.5 – 108.0 MHz
MW: 531 – 1602 kHz
LW: 153 – 279 kHz
Input sensitivity AM: 27 dBµV at 20 dB S/N
FM: 5 dBµV at 26 dB S/N
LW: 30 dBµV at 20 dB S/N
Signal-to-noise ratio FM/ AM: 55 dB
Stereo channel separation 26 dB
CASSETTE COMPONENT
Tape speed 4.76 cm/ sec.
Wow and flutter < 0.35 %
Signal-to-noise ratio > 50 dB with Dolby
Cross talk > 40 dB
Frequency response 30 – 12,000 Hz
