CLIMATE CONTROL AND AUDIO SYSTEM 4–81
Power supply Direct current 14.4 V
Loudspeaker impedance 4 – 8 ohm (4 loudspeakers)
Output power In accordance with DIN 45 324 at 14.4 V / 4 x 40 watts max. power
Frequency range FM: 87.5 – 108.0 MHz
MW: 531 – 1602 kHz
LW: 153 – 279 kHz
Input sensitivity FM: 6 dBaV at 26 dB S/N
MW/ LW: 6 dBaV at
26 dB S/N
Signal-to-noise ratio FM/ AM: 55 dB
Stereo channel separation 26 dB
Frequency response -3 dB x 1 dB
Signal-to-noise ratio dB A 75 dB
Stereo crosstalk (1kHz) 67 dB
Distortion (1kHz) 0.15%
SPECIFICATIONS (EXCERPTS)
RADIO COMPONENT
CD COMPONENT
