Local Configurations 100
5.4.4.2 Calling Tours
On the Expanded PTZ Control Panel, in the No. box, enter the value of the tour that
Step 1
you want to call.
Click to call the tour. Step 2
Click again to stop calling the tour. Step 3
5.4.4.3 Calling Patterns
On the Expanded PTZ Control Panel, in the No. box, enter the value of the pattern that Step 1
you want to call.
Call to call the pattern. Step 2
The PTZ camera moves according to the configured pattern repeatedly.
Click again to stop calling the pattern. Step 3
5.4.4.4 Calling AutoScan
On the Expanded PTZ Control Panel, in the No. box, enter the value of the border that Step 1
you want to call.
Click . Step 2
The PTZ camera performs scanning according to the configured borders.
Click again to stop auto scanning. Step 3
5.4.4.5 Calling AutoPan
On the Expanded PTZ Control Panel, click to start moving in horizontal direction. Step 1
Click again to stop moving. Step 2
5.4.4.6 Using AUX Button
On the Expanded PTZ Control Panel, click , the AUX setting interface is displayed. See
Figure 5-65.
In the Direct Aux list, select the option that corresponds to the applied protocol.
In the Aux Num box, enter the number that corresponds to the AUX switch on the decoder.
