Local Configurations 109
Click Copy to copy the settings to other channels.
5.5.2.3 Encode Enhancement
Only some series products support encode enhancement.
Enabling or disabling this function will take effect after the device is rebooted.
This function is disabled by default. After it is enabled, when main stream resolution is 4K, the
frame rate can be 10 fps.
Select Main Menu > CAMERA > ENCODE > Encode Enhancement. Step 1
The Encode Enhancement interface is displayed. See Figure 5-72.
Figure 5-72
Click behind Encode Enhancement, to enable this function.
Step 2
5.5.3 Configuring Overlay Settings
You can configure to display system time and channel name on each channel window in the live
view screen.
Select Main Menu > CAMERA > OVERLAY > Overlay. Step 1
The Overlay interface is displayed. See Figure 5-73.
