Local Configurations 106
Figure 5-70
Configure the settings for the main/sub streams parameters. See Table 5-24. Step 2
In the Channel list, select the channel that you want to configure the
settings for.
Enable the smart codec function. This function can reduce the video
bit stream for non-important recorded video to maximize the storage
space.
Main Stream: In the Type list, select General, MD (Motion
Detect), or Alarm.
Sub Stream: This setting is not configurable.
In the Compression list, select the encode mode.
H.265: Main profile encoding. This setting is recommended.
H.264H: High profile encoding. Low bit stream with high
definition.
H.264: General profile encoding.
H.264B: Baseline profile encoding. This setting requires higher bit
stream compared with other settings for the same definition.
In the Resolution list, select resolution for the video.
The maximum video resolution might be different dependent on your
device model.
