Local Configurations 243
Figure 5-208
Configure the settings for the SNMP parameters. See Table 5-66. Step 2
Enable the SNMP function.
Select the check box of SNMP version(s) that you are using.
The default version is V3. There is a risk of select V1 or V2.
Indicates the monitoring port on the agent program.
Indicates the read/write strings supported by the agent program.
Indicates the destination address for the agent program to send the
Trap information.
Indicates the destination port for the agent program to send the
Trap information.
Enter the user name that is allowed to access the Device and has
the "Read Only" permission.
Enter the user name that is allowed to access the Device and has
the "Read and Write" permission.
Includes MD5 and SHA. The system recognizes automatically.
Enter the password for authentication type and encryption type.
The password should be no less than eight characters.
