Dahua DH-VTO9221D

30
Parameter Note
Family
Name
Set VTH username.
First Name
VTH Short
No.
As VTH room no.
Note:
 VTH short no. is composed of 1-5 digits of number.
 If your VTH room no. need group call function, please make sure you
have enabled group call in System Config>LAN Config>LAN Config, and
add “-0” behind VTH short no., add “-1”, “-2
” and so forth behind
extension short no. Otherwise, VTH will only calls main VTH when dial
the room no.
Register
Password
SIP system signal command interacting, use default is OK.
Register
Type
Step 6. Click OK, to complete VTH, see Figure 5-12.
Figure 5-12
 Batch add VTH
Batch add multiple VTHs, up to 1024.For example, add 5 floors and each floor has 4 VTH.
Step 1. Select System Config>LAN Config>Residence Config. System shows Residence
Config interface.
Step 2. Configure parameter, see Figure 5-13.
