36
Parameter Note
Username
SIP server login username and password.
Default username is VTO no., and default password is 888888.
Password
SIP Domain SIP server domain, can be null.
Step 2. Enter parameter.
Step 3. Click OK.
5.2.4.4 Port Config
Step 1. Select System Config>Network Config>Port Config. See Figure 5-21.
Figure 5-21
Step 2. Configure parameter, see chart below.
WEB Port
Set port to login unit VTO WEB interface, default is 80；you also
can go to VTO host “project setting > WEB port” to view WEB
port no.
If the port is occupied, you can use 1025~65535 range, in
browser enter “http://VTO IP
：
WEB port no.”to visit VTO WEB
interface.
SIP Port SIP server port, default is 5060.
RTP Port Video pull stream port, default is 15000.
SIP Router Add Check “Enable” to enable router function.
Click “router setup”, in pop-
up box enter H700 platform IP
address, port no. is 5080.
Setting
Step 3. Click OK.
