Dahua DH-XVR54 L-I2 Series User Manual

User’s Manual
110
Overlay
Configure the settings for the text overlay parameters.
Table 5-22 Overlay parameters
Parameter Description
Channel
In the Channel list, select the channel that you want to configure the settings
for.
Time Title
Select the Time Title checkbox to display the system time on each channel
window in the live view screen.
In the Time Title list, select time display style.
Channel Title
Select the Channel Title checkbox to display the channel name on each
channel window in the live view screen.
In the Channel Title box, enter the name for the selected channel.
Click Apply to complete the settings.
Click Copy to to copy the settings to other channels.
5.5.6 Configuring Covered Area Settings
Select Main Menu > CAMERA > Overlay > Privacy Masking.
