User’s Manual
70
Snapshot
Configure the snapshot settings parameters.
Parameter Description
Channel
In the Channel list, select a channel to take a snapshot.
Event type
Select the checkbox of the event type which includes General, Motion,
Alarm, M&A, Intelligent, and POS.
Period
Define a period during which the configured snapshot setting is active. For
details about defining a period, see "5.1.4.9 Configuring Recorded Video
Storage Schedule".
Copy
Click Copy to copy the settings to other channels.
Click OK.
Click OK.
The live view screen is displayed. The setting up with startup wizard is completed. You can
start using the Device.
(Optional) After the setting with startup wizard is completed, if the connected HDMI display
resolution is inconsistent with default resolution (1280 × 1024), a dialog box will pop up.
Choose to switch the resolution or not.
Change resolution
