User’s Manual
86
Zero-channel
Configure the settings for the zero-channel parameters.
Table 5-13 Zero-channel parameters
Parameter Description
Enable Enable zero-channel function.
Compression
In the Compression list, select the video compression standard according
to the device capability. The default is H.265.
Resolution
In the Resolution list, select the video resolution. The default is 704 × 576
(D1).
Frame Rate (FPS)
Select a value between 1 and 25 for PAL standard, and between 1 and 30 for
NTSC standard. The actual arrange is decided and selected dependent on
the Device capability.
Bit Rate (Kb/S)
The default value is 1024Kb/S. The actual arrange is decided and selected
dependent on the Device capability and frame rate.
Click Apply to save the settings.
In the live page on the web, click to select one of the multi-
channel modes, and then you can view the local video image.
5.2.8.3 Configuring TV
This function is available on select models.
You can adjust the border margins in top, bottom, left and right directions as well as the brightness of
the monitor connected to the Video out port of the Device.
Select Main Menu > DISPLAY > TV Adjust.
