User’s Manual
170
Face detection
In the Channel list, select a channel that you want to configure face detection function, and
then enable it.
Configure the parameters.
Table 5-33 Face detection parameters
Type
You can select from
and
.
: This option requires certain AI cameras. The camera
will do all the AI analysis, and then give the results to the DVR.
: The camera only transmits normal video stream to
the DVR, and then the DVR will do all the AI analysis.
Rule
Click
to draw areas to filter the target.
You can configure two filtering targets (maximum size and minimum
size). When the target is smaller than the minimum size or larger than
the maximum size, no alarms will be activated. The maximum size
should be larger than the minimum size.
Schedule
Define a period during which the detection is active.
For details, see "Setting Motion Detection Period" section in "5.10.4.1
Configuring Motion Detection Settings."
