37
Figure 4-24
Please refer to the following sheet for detailed information.
Parameter Function
Enable You need to check the box to enable this function.
Sensitivity
There are six levels. The sixth level has the highest sensitivity.
Area
z
There are six levels. The sixth level has the highest sensitivity.
z
Region: you can click this button to set Video masking zone.
The interface is shown as in Figure 4-24. There are PAL
22X18/NTSC 22X15 zones. Right click mouse you can go to
full-screen display mode. Do remember clicking OK button to
save your Video masking zone setup.
Working
Period
z
Video masking function becomes activated in the specified
periods.
z
There are six periods in one day. Please draw a circle to enable
corresponding period.
z
Select date. If you do not select, current setup applies to today
only. You can select all week column to apply to the whole
week.
z
Click OK button, system goes back to motion detection
interface, please click save button to exit.
Anti-dither
System only memorizes one event during the anti-dither period.
The value ranges from 0s to 100s.
