Dahua IPC-HFW2100P Series User Manual

2
 6SHFLILFDWLRQV
Please refer to the following sheet for IPC performance specification.
Model
Parameter
IPC-HFW2100P/N Series
Main Processor TI Davinci high performance DSP
OS Embedded LINUX
System
Resources
Support real-time network, local record, and remote operation at the
same time.
User Interface Remote operation interface such as WEB, DSS, PSS
System
System Status Bit stream statistics, log, and software version.
Image Sensor 1/3-inch CMOS
Pixel 1280(H)*960(V)
Gain Control Fixed/Auto
White Balance Manual/Auto
Exposure Mode
Manual/Auto
PAL: It ranges from 1/3 to 1/10000
NTSC: It ranges from 1/4 to 1/10000
Video
Compression
Standard
H.264/JPEG/MJPG
PAL:
Main stream(1280*960@15fps),
extra stream,˄352*288@15fps)˅
Main stream˄1280*720@25fps˅ˈ
extra stream˄352*288@25fps˅
Video Frame
Rate
NTSC:
Main stream˄1280*960@15fps˅ˈ
extra stream˄352*240@15fps˅
Main stream˄1280*720@30fps˅ˈ
extra stream˄352*240@30fps˅
Video Bit Rate
H.264: 56Kbps-8192Kbps.
MJPEG is adjustable and bit rate is adjustable.
Support customized setup.
Video Flip
Support mirror.
Support flip function.
Snapshot Max 1f/s snapshot. File extension name is JPEG.
Privacy Mask Supports max 4 privacy mask zones
Video Setup Support parameter setup such as bright, contrast.
Video
Information
Channel title, time title, motion detect, camera masking.
Lens 3.6mm, 6mm, 8mm. Fixed focus.
Video Parameter
Lens Interface M12. Lens is the default accessories
Video
Motion Detect
396 (18*22) detection zones˗sensitivity level ranges from 1 to 6 (The
6
th
level has the highest sensitivity)
Activation event: video storage, image snapshot, log, email function
and etc.
Record Priority Manual>External alarm >Video detect>Schedule
Record and Backup
Storage
Management
Support display local storage status
