43
There are three record modes: general (auto), motion detect and alarm. There are six periods in one
day. Please make sure you have enabled the corresponding record mode in the Setup->Storage-
>Conditions.
You can view the current time period setup from the color bar.
z Green color stands for the general record/snapshot.
z Yellow color stands for the motion detect record/snapshot..
z Red color stands for the alarm record/snapshot.
Figure 4-32
4.4.2 Destination
The destination interface is shown as in Figure 4-33.
It is to set the storage mode of the IPC record file or snapshot pictures. There are three options:
local/FTP/network. You can only select one mode. System can save according to the event types. It is
corresponding to the three modes (general/motion/alarm)in the Schedule interface. Please check the
box to enable the save functions.
Figure 4-33
Please refer to the following sheet for detailed information.
