19
Add channel
Table 3-7 Description of adding channel
Parameter Description
Protocol
You can select from Acquisition (IP camera, IVSS (intelligent video surveillance
server)), DSS, and PSS (SmartPSS), depending on the device connected.
IP Address
IP address of device (IP camera, IVSS), DSS, or PSS, depends on the Protocol that you
select.
Username Username and password for logging in to IP camera or IVSS.
You need to enter the username and password when Acquisition is selected from
Protocol.
Password
Port
Port for logging in to IP camera, IVSS, DSS, or PSS.
It is 37777 by default for IP camera and IVSS, and 8101 for DSS and PSS.
Channel
You need to enter channel No. when IP camera or IVSS is connected.
Enter 1 when IP camera is connected.
Enter the number of channels that you want to display when IVSS is connected.
Stream
Type
Main stream: Provides large bit stream and images with high resolution, but
requires large bandwidth.
Sub stream: Provides small bit stream and smooth image, and requires less
bandwidth.
Click Confirm, and then configure other parameters.
Table 3-8 Description of other parameters
Parameter Description
Display Video
●
Screen split
: You can view the video image of the added channels by 1, 2, 3, or
4 splits.
●
Switching time(seconds)
: Switch to play video of another added channel after
the defined time.
●
Channel selection
: Select the channel to be played in each screen split.
