Dahua Lite series User Manual

Design 4
Table 2-1 Cable function
No.
Port Name
Function
①
12V DC Power
Input
Inputs 12V DC power. Please be sure to supply power as
instructed in the Manual.
Device abnormity or damage could occur if power is not
supplied correctly.
②
Video Output
Connects to XVR to output video signal.
③
Audio Input
Connects to sound-pick-up devices to receive audio signal.
④
DIP Switch
Dial switches to change output mode. Switch up indicates "ON",
switch down indicates "OFF."
Table 2-2 DIP switch operation
Switch1
Switch2
Output Mode
OFF
OFF
CVI
ON
ON
CVBS
ON
OFF
AHD
OFF
ON
TVI

Dahua Lite series Specifications

General

Brand	Dahua
Model	Lite series
Category	Security Camera
Language	English
