Dahua N82B3P

User's Manual
6
Icon
Name
Function
POWER
Power status indicator
light
The blue light is on when the power
connection is OK.
USB port
Connect to peripheral USB storage device,
mouse and more.
2.1.2
N42C1P/N42C2P/N42C3P/N52B5P/N54A4P/N54B3P/N54B5N
The figures are for reference only.
The N42C1P/N42C2P/N42C3P/N52B5P/N54A4P/N54B3P/N54B5N series front panel is
shown as below.
Figure 2-4 Front panel
The N42C1P/N42C2P/N42C3P/N52B5P/N54A4P/N54B3P/N54B5N series front panel is
shown as below.
Figure 2-5 Front panel
The N42C1P/N42C2P/N42C3P/N52B5P/N54A4P/N54B3P/N54B5N series front panel is
shown as below
Figure 2-6 Front panel
Table 2-3 Icons
Icon
Name
Function
STATUS
Status indicator light
The blue light is on when the
Device is working properly.
