User's Manual
301
Figure 5-260 Tour
●
On the top right of the live view screen, use the left mouse button or press Shift
to switch between (image switching is allowed) and (image switching is
not allowed) to turn on/off the tour function.
●
On the navigation bar, click to enable the tour and click to disable it.
Step 2 Configure the tour setting parameters.
Table 5-79 Tour parameters
Enter the amount of time that you want each channel group
displays on the screen. The value ranges from 5 seconds to 120
seconds, and the default value is 5 seconds.
Select the View 1 or View 8 for Motion Tour and Alarm Tour
(system alarm events).
In the Live Layout list, select View 1, View 4, View 8, or other modes
that are supported by the Device.
