32
Window
Split
1/4/8/9/16/25/36-window
Audio
Audio
Input
1-ch bidirectional talk input
Audio
Output
1-ch bidirectional talk output
Audio
Compres
sion
G.711a, G.711u, PCM, G.726 (The bidirectional talk function supports
G.711a, G.711u, PCM only.)
Alarm
Alarm
Input
4-ch alarm input
Alarm
Output
3-ch relay output
Function
Storage
2 built-in SATA ports.
Multiple-c
hannel
Playback
Max 64-channel D1/32-channel 720P/16-channel 1080P/4-channel 4K
playback at the same time.
Record
Mode
Overwrite
Backup
Mode
Flash disk, DVD burner.
Port and
Indicator
Network
Protocol
IPv4/IPv6/HTTP/UPnP/NTP/SADP/SNMP/PPPoE/DNS/FTP/ONVIF(Versio
n 2.4)/PSIA
RS232
Port
One RS232 port to debug transparent COM data.
RS485
port
One RS485 port to control PTZ. Support various protocols.
USB Port
2 peripheral USB ports: One USB2.0 at the front panel and one USB3.0 at
the rear panel.
Network
Connecti
on
One RJ45 10/100/1000Mbps self-adaptive Ethernet port.
Power
Port
One power socket. Power adapter power supplying. Input DC 12V-4A
power.
Power
Button
One button. At the rear panel.
Power
On-off
Button
N/A
IR
Receiver
Window
N/A
