46
Function
Storage
4 built-in SATA ports. 1 external eSATA port.
Multiple-c
hannel
Playback
Max 16-channel 720P/8-channel 1080P playback at the same time.
Port and
Indicator
RS232
Port
One RS232 port to debug transparent COM data.
RS485
port
One RS485 port to control PTZ. Support various protocols.
USB2.0
Port
3 peripheral USB2.0 ports. One at the front panel and two at the rear panel.
Network
Connecti
on
Two RJ45 10/100Mbps
self-adaptive Ethernet
ports.
One RJ45 10/100Mbps self-adaptive Ethernet
port.
Power
Port
One power port. Input 100-240V50~60Hz.
Power
Button
One button. At the rear panel.
Power
On-off
Button
One button. At the front-panel.
IR
Receiver
Window
Support IR remote control
Clock
Built-in clock.
General
Indicator
Light
One power status indicator light.
One network status indicator light.
One HDD status indicator light.
Power
Consump
tion
30W(No HDD)
Working
Temperat
ure
-10℃~+55
Working
Humidity
10℅90℅
Air
pressure
86kpa106kpa
Dimensio
n
1.5U, 440mm × 460mm × 68mm
Weight
5kg6kgNo HDD
Installatio
n
Desk installation
