User's Manual
126
Figure 4-34
● When the record type is Motion (motion detection), alarm, M&A, IVS and POS,
enable the channel record function when corresponding alarm occurs. For
example, when the alarm type is MD, select
Main Menu
>
ALARM
>
Video
Detection
>
Motion Detection
, select the record channel and enable record
function.
● When the record type is Motion (motion detection), alarm, M&A, IVS and POS,
refer to "4.8.5 Video Detection", "4.8.3 Alarm Input", "4.7.1.3 IVS" and "4.9 POS"
for detailed information.
Figure 4-35
Step 4 Set record period. It includes edit mode and draw mode. See Figure 4-38.
To Next Page
