Dahua NVR1104HS-W Series User Manual

User's Manual
5
No.
Name
Function
2
Power indicator light
The red light becomes on when the
power connection is OK.
3
Network status indicator light
The red light becomes on when the
network connection is abnormal.
2.1.2 NVR41H/41H-P/41H-8P Series
The front panel is shown as in Figure 2-2.
Figure 2-2 Front panel
Table 2-2
Icon
Name
Function
NET
Network status indicator light
The red light becomes on
when the network connection
is abnormal.
PWR
Power indicator light
The red light becomes on
when the power connection is
OK.
HDD
HDD status indicator light
The red light becomes on
when HDD is abnormal.
IR
Remote control receiver
It is to receive signal from the
remote control.
2.1.3 NVR41HS-W-S2 Series
The front panel is shown as below. See Figure 2-3.
