User's Manual
84
NVR42/42-P/42-8P/42-16P/52-4KS2/52-8P-4KS2/52-16P-4KS2/52
24-24P-4KS2/52-8P-4KS2E/52-16P-4KS2E Series
See Figure 3-46for connection sample.
The following figure is for reference only.
Figure 3-46
3.6.8
NVR42-8P-4K/42-4KS2/42-P-4KS2/42-8P-4KS2/42-16P-4KS2
Series
See Figure 3-47 for connection sample.
