User's Manual
129
Enable auto record function so that the record plan can become activated. Refer to
"4.1.4.6.3 Record Control" for detailed information.
4.1.4.6.2 Snapshot Schedule
You can set schedule snapshot period.
After set schedule snapshot, device can snapshot image according to the period you set here.
For example, the alarm snapshot period is from 6:00–18:00 Monday, device can snapshot
during the 6:00–18:00 when an alarm occurs.
Step 1 Click
Snapshot
, the device goes to following interface. See Figure 4-39.
Select
Main Menu
>
STORAGE
>
Schedule
>
Snapshot
, you can go to the
snapshot interface.
Figure 4-39
Step 2 Select a channel to set schedule snapshot.
Step 3 Set snapshot type as schedule. Refer to "4.2.6.2 Snapshot" for detailed information.
Step 4 Check the box to set alarm type. See Figure 4-40.
To Next Page
