Dahua NVR1104HS-W Series User Manual

User's Manual
63
No.
Name
Function
7
Play/Pause
● In normal playback state, press this button to
pause playback.
● In pause state, press this button to resume to
normal playback.
● In live view window interface, press this button
to enter video search menu.
8
Reverse/pause
In the reverse playback state, press this button to
pause reverse playback.
In the reverse playback pause state, press this
button to resume to playback reversing state.
9
Esc.
Go back to previous menu or cancel current
operation (close front interface or control).
10
Record
● Start or stop record manually.
● In record interface, use the direction buttons to
select the channel that you want to record.
● Press this button for at least 1.5 seconds, and
the manual record interface will be displayed.
11
Direction keys
Switch between current activated controls by going
left or right.
In playback state, the keys control the playback
progress bar.
Aux function (such as operating the PTZ menu).
12
Enter/menu key
● Confirms an operation.
● Go to the OK button.
● Go to the menu.
13
Multiple-window
switch
Switch between multiple-window and one-window.
14
Fn
● In single-channel monitoring mode, press this
button to display the PTZ control and color
setting functions.
● Switch the PTZ control menu in PTZ control
interface.
● In motion detection interface, press this button
with direction keys to complete setup.
● In text mode, press and hold this button to
delete the last character. To use the clearing
function: Long press this button for 1.5
seconds.
● In HDD menu, switch HDD recording time and
other information as indicated in the pop-up
message.
15
Alphanumeric keys
● Input password, numbers.
● Switch channel.
● Press Shift to switch the input method.
