2.1 Condition Settings
2-3
Fig. 2.1.2 Selector switch for enabling/disabling operations always provided
at upper right-hand corner of each page
On the same setting screen, align the cursor with "Common Switch", and set the
desired status.
Settings Details
Previous No. Restore the status in which the power is previously turned off.
Disabled The switch is always set to "Disabled" when the power is turned on.
1
Put the cursor on “Common switch ON direction”, and set it to the desired status.
Settings Details
Left Inhibit operations on the left side.
Right Inhibit operations on the right side.
2
Put the cursor on “Common switch operation method”, and set it to the desired
status.
Settings Details
Standard Enable operation without pressing the [ENABLE] key.
Enable No operations are enabled unless the [ENABLE] key is pressed.
3
4
Upon completion of settings mentioned above, press the f12 <Complete> key.
2.1.4 Setting of Enable/Disable of functionless code switch name setting
Using the “Interface panel design” menu, make setting of whether or not the name setting of switches, to which the
functionless code (0) is set, is to be enabled.
On the same setting screen, put the cursor on “Functionless code name setting”,
and set it to the desired status.
Settings Details
Hide Make setting so that the name setting of switch, to which the
functionless code has been set, will not be displayed. The name
setting will also be disabled.
Display Make setting so that the name setting of switch, to which the
functionless code has been set, will be displayed. The name setting
will also be enabled.
1
2
Upon completion of settings mentioned above, press the f12 <Complete> key.
