Daikin BRC1E51 - 8. Permission level function; 9. Field settings

Quick reference
5
BRC1E51
Remote controller
4PW52905-1
8. Permission level function
■ If required, you can limit the user action by
restricting the number of operable buttons. (Refer
to the chapter “Field settings” on page 5).
■ For switching between level 1 permission and the
selected level in service, proceed as follows
(refer to figure 7):
1 Keep the button pressed,
2 and push the 3 other indicated keys
simultaneously while keeping the button
pressed.
■ If you want to limit the user action on the remote
controller to be defined as “sub”, start with only
connecting this controller to the unit. Make sure
that this controller is set to “main” (factory set)
first, change the permission level to the setting
you prefer and only then set the remote controller
to “sub” (Refer to the chapter “Field settings” on
page 5).
You can now proceed with connecting the remote
controller to be defined as “main”.
9. Field settings
If optional accessories are mounted on the indoor
unit, the indoor unit setting may have to be changed.
Refer to the instruction manual for each optional
accessory.
Procedure
1 Press and hold the button for four
seconds to enter the Field setting menu.
2 Use the buttons to select Field setting list
and push the button.
Level Operable buttons
1 All
2 • Up/down button
• On/off button
• Operation mode selector button
3 • On/off button
NOTE When pushing a non-operable button, the
icon will be displayed.
a Unit No
b First Code No
c Second Code No
d Mode
e Field set mode
Mode
20
Unit No
0
1
–
00
5
–––
9
–––
2
–
00
6
–––
a
–––
3
–
00
7
–––
b
–––
Field setting list
0
–
01
4
–––
8
–––
Return Setting
a
e
b
c
d
Return Setting
Field setting
Test operation ON/OFF
Register Service Contract
Field setting list
Group No. setting
Indoor unit Airnet No. set
Outdoor unit Airnet No. set
1/2
