12
Double face tape
Holder
The back side
of the holder
TYPE A2
Position of the Wireless LAN connecting adapter on the wall/surface is fixed by double face tapes.
In this case screws located in accessory set are not necessary to fix the holder.
1. Attach two double face tapes located in accessory set to the back side of
holder as shown below.
2. Fix the Wireless LAN connecting holder on the wall/surface with the double face tapes.
3. Make sure that holder is fixed to the wall/surface enough to support the Wireless LAN
connecting adapter.
4. Attach the Wireless LAN connecting adapter to the holder by sliding into it.
NOTE
For any updated details about installation of the Wireless LAN connecting adapter for your model,
please visit http://www.daikinthai.com/product/dmobile.
Wall/surface should be clean and degreased before attaching of the Wireless LAN connecting
holder by double face tapes.
Installation
Installation
Installation
Work
Wireless LAN connecting
adapter (External)
To Next Page
