3 | Components
Service manual
106
EBLA09~16DA + EDLA09~16DA
Daikin Altherma 3 M
ESIE20-06A – 2021.03
3 Connect the Megger ground test lead directly to the backup heater ground
wire.
CAUTION
Do NOT connect the Megger ground test lead to any other ground wire.
4 Measure the insulation resistance between the following terminals. The
measured insulation resistance MUST be >3MΩ.
Terminals
K1M1‑ground
K1M3‑ground
Is the measured backup heater
insulation resistance correct?
Action
Yes Return to "Checking
procedures"[4104] of the backup
heater and continue with the next
procedure.
No Replace the backup heater, see "Repair
procedures"[4108].
To perform an electrical check of the backup heater
Prerequisite: First perform an insulation check of the backup heater, see "Checking
procedures"[4104].
Prerequisite: Check the circuit breaker. Reset if it has tripped.
Prerequisite: Check that the backup heater thermal protector functions correctly.
Reset if it has tripped. See "3.4Backup heater thermal protector"[4121].
1 Turn ON the power of the unit.
INFORMATION
If the circuit breaker or the backup heater thermal protector trips again, determine
the root cause of the problem. Something is overloading the electrical circuit or
creating a short-circuit.
2 Activate Installer on the user interface. See the installer reference guide
for the correct procedure.
3 Go to Actuator test run via the user interface.
4 Activate backup heater: step 1.
5 Check the status in the Actuators menu of the user interface. This MUST be:
▪ Backup heater: step 1 = ON
6 Check if the field installed circuit breaker has tripped.
Did the fuse blow or did the field
supplied circuit breaker of the backup
heater trip?
Action
Yes Replace the backup heater, see "Repair
procedures"[4108].
