Specifications SiBE01-829
6 Specifications
1. Specifications
50Hz 230V
Note:
The data are based on the conditions shown in the table below.
Models
Indoor Units FTYN25GXV1B FTYN35GXV1B
Outdoor Units
RYN25GXV1B RYN35GXV1B
Cooling Heating Cooling Heating
Capacity
Rated (Min.~Max.)
kW 2.5 2.85 3.27 3.68
Btu/h 8,500 9,700 11,200 12,600
kcal/h 2,150 2,450 2,810 3,160
Running Current (Rated) A 3.4 3.5 4.8 4.8
Power Consumption
Rated (Min.~Max.)
W 770 780 1,020 1,020
Power Factor % 98.5 98.6 93.4 92.4
COP (Rated) W/W 3.25 3.65 3.21 3.61
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
12.7
Drain mm
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 15 15
Max. Interunit Height Difference m 10 10
Chargeless m 10 10
Amount of Additional Charge
of Refrigerant
g/m 20 20
Indoor Units FTYN25GXV1B FTYN35GXV1B
Front Panel Color White White
Airflow Rate
m³/min
(cfm)
H 9.5 (335) 9.7 (342) 9.8 (346) 10.5 (371)
M 7.9 (279) 8.1 (286) 8.3 (293) 8.8 (311)
L 6.3 (222) 6.6 (233) 6.8 (240) 7.1 (251)
SL 5.9 (208) 6.2 (219) 6.4 (226) 6.7 (237)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 3 Steps, Quiet, Auto 3 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.2 0.2 0.2 0.2
Power Consumption (Rated) W 37 37 37 38
Power Factor % 79.7 79.7 80.4 82.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 288×800×204 288×800×204
Packaged Dimensions (H×W×D) mm 288×874×360 288×874×360
Weight kg 9 9
Gross Weight kg 13 13
Operation
Sound
H/M/L/SL dBA 38 / 32 / 27 / 25 38 / 33 / 27 / 25 38 / 34 / 29 / 27 40 / 35 / 29 / 27
Outdoor Units RYN25GXV1B RYN35GXV1B
Casing Color White White
Compressor
Type Hermetic Motor Compressor Hermetic Motor Compressor
Model 5PS102DAK01 5PS132DBB01
Motor Output W 700 900
Refrigerant
Oil
Type RB68A / FREOL ALPHA68M RB68A / FREOL ALPHA68M
Charge L 0.35 0.35
Refrigerant
Type R-410A R-410A
Charge kg 0.80 1.10
Airflow Rate
m³/min 34.9 31.6 31.4 28.1
cfm 1,232 1,116 1,108 991
Fan
Type Propeller Propeller
Motor Output W 26 26
Running Current (Rated) A 3.2 3.3 4.6 4.6
Power Consumption (Rated) W 733 743 983 982
Power Factor % 99.6 97.9 92.9 92.8
Starting Current A 17.0 23.5
Dimensions (H×W×D) mm 550×765×285 550×765×285
Packaged Dimensions (H×W×D) mm 358×611×899 358×611×899
Weight kg 31 34
Gross Weight kg 35 38
Operation
Sound
H dBA 48 49 49 52
Drawing No. 3D060315 3D060316
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
5m
