Functions SiBE01-829
14 Functions and Control
1. Functions
1.1 Power-Airflow Flap, Wide-Angle Louvers and Auto-
Swing
Power-Airflow
Flap
The large flap send a large volume of air downwards to the floor. The flap provides an optimum
control area in cooling, heating and dry mode.
Heating Mode
During heating mode, the large flap enables direct warm air straight downwards. The flap
presses the warm air above the floor to reach the entire room.
Cooling Mode
During cooling mode, the flap retracts into the indoor unit. Then, cool air can be blown far and
pervaded all over the room.
Wide-Angle
Louvres
The louvres, made of elastic synthetic resin, provide a wide range of airflow that guarantees a
comfortable air distribution.
Auto-Swing The following table explains the auto-swing process for heating, cooling, dry and fan :
Vertical Swing (up and down)
Horizontal Swing
(right and left: manual)
Cooling, Dry, Fan Heating
50˚
70˚
(R8483)
105˚
65˚
(R8484)
45˚
45˚
(R8485)
To Next Page
