SiBE01-829 Indoor Unit
Removal Procedure 61
3
Pull out the air filter
downwards and remove
it.
3. Removing the air purifying
filter
1
The air purifying filter is
attached to the back of
the air filter.
2
Remove the air
purifying filter frame by
bending the air filter
and unfastening the
projections from the air
filter frame.
3
Remove the air
purifying filter from its
frame (at 5 positions)
by bending it.
To prevent the damage, do
not remove the flame when
cleaning the filter.
The shape of filter varies
depending on the model.
The air-purifying filter is not
marked for difference
between the right and left
sides.
Step Procedure Points
(R8570)
Air filter
(R8636)
Air purifying
filter
Projections
(R8026)
Hook
(R8027)
To Next Page
