DAIKIN CONTAINER
LXE10E-A
TR 01-09B
Marine type
Container Refrigeration Unit
Service Manual
PDF作成用LXE10E-A2007.02.2617:53ページ1
https://daikin-p.ru

Table of Contents

Questions and Answers

  • J
    jordanwadeAug 2, 2025
    How to troubleshoot Daikin LXE10E-A that does not operate?
    • G
      Glen TorresAug 2, 2025
      If your Daikin Air Conditioner unit isn't operating, the issue might stem from a faulty power supply. Ensure the power supply is functioning correctly. It could also be due to a failure in the evaporator fan's operation; in this case, make sure the condenser fan is stopped while high pressure is under control by increasing the high pressure and ensuring the evaporator fan stops when the HPT is 1000 kPa or more. Check if the switch is turned on. Another potential cause is the secondary side of the power supply transformer. Inspect for any disconnection of Fu1 (fuse) and check for any malfunction in object models. Finally, check for disconnection on the secondary side of the transformer (Tr), and if found, replace the transformer.
  • O
    olsonlaurieAug 16, 2025
    What to do if condenser fan and compressor run, but evaporator fan does not run on Daikin LXE10E-A?
    • D
      david71Aug 16, 2025
      If the condenser fan and compressor of your Daikin Air Conditioner run, but the evaporator fan does not, it could be due to a faulty electrical system of the evaporator fan, CTP running, motor seizure (disconnection), or a disconnected coil of the electromagnetic contactor. In this case, replace the fan motor or the electromagnetic contactor. Also, check for any external factors, such as foreign matter, and remove them.

Summary

SAFETY PRECAUTIONS

DANGER

Critical safety warnings regarding high voltage and immediate hazards.

WARNING

Important safety precautions to prevent severe personal injury or equipment damage.

CAUTION

Precautions to prevent minor injury or equipment damage during operation.

1. INTRODUCTION

1.1 Operation range

Specifies the ambient and internal temperature, voltage, and shock limits for unit operation.

1.2 Basic names of components

Identifies key external components of the refrigeration unit with labels and descriptions.

1.3 Basic operation of refrigeration unit

Details the fundamental steps for starting, checking, and shutting down the refrigeration unit.

2. GENERAL DESCRIPTION

2.1 Main specifications

Lists the technical specifications of the LXE10E model, including cooling system, power, and components.

2.5 Operation modes and control

Explains the different operational modes like Chilled, Frozen, Partial Frozen, and Defrosting.

3. ELECTRONIC CONTROLLER

3.2 Basic operation of electronic controller

Describes the control panel layout, LEDs, LCD, and operation keys for the electronic controller.

3.3 Operation procedure

Outlines the sequence of operations for accessing various modes and functions of the controller.

3.4 Alarm display and back-up function

Lists and explains alarm codes, their causes, and backup operations for sensor malfunctions.

4. SERVICE AND MAINTENANCE

4.1 Maintenance service

Covers essential maintenance tasks like refrigerant handling and gauge manifold usage.

4.2 Main components and maintenance

Provides detailed procedures for replacing major components like compressors and fans.

6. TROUBLESHOOTING

6.1 Refrigeration system and electrical system

Provides a systematic guide to diagnose and resolve issues related to the refrigeration and electrical systems.

6.2 Alarm codes on electronic controller

Lists and explains alarm codes generated by the electronic controller, including possible causes.

6.5 Emergency operation

Details procedures for emergency operation of the controller and its components.

7. APPENDIX

7.1 Standard tightening torques for bolts

Lists standard tightening torques for various bolts used in the unit assembly.

7.10 Piping diagram

Illustrates the refrigerant piping layout of the LXE10E unit, showing component connections.

7.13 Schematic wiring diagram (Connector type terminal board and rechargeable battery)

Shows the electrical wiring connections for the controller, recorder, and battery using connector types.

8. OPTIONAL FUNCTIONS MANUAL

8.1 Electronic temperature recorder

Details the standard type electronic temperature recorder, its specifications, and operation.

8.2 Electronic controller

Explains special operations, modes, and settings for the electronic controller.

8.4 USDA transportation

Outlines requirements and procedures for USDA transportation, including sensor types and calibration.
