(3)
Pre-filter (green)
(2)
Water tank
(6)
Pleated filter
(front: white, back: blue)
(5)
(Streamer unit)
UNIT2
(4)
(Plasma ionizer)
UNIT1
(1)
Front panel
(7)
Deodorizing catalyst unit
• Air inlets for Dust/Odor
sensors and Temperature/
Humidity sensors
Humidifying tray
• Recyclable deodorizing cartridge
Humidifying filter
Page 33, 34.
Page 33, 34.
Page 30, 31.
Page 27.
Page 27.
Page 28.
Page 28.
Page 28.
Page 35.
Page 36.
Page 29.
To clean the humidifying tray or humidifying filter, first remove the (1) front panel and remove the (2) water tank.
To Next Page
