Table 23 continued: Unit Conguration Menu
Conguration
Code Position
Description Values (Default in Bold) Special Condition RTU MPS DPS DPH SCU
6 Low Ambient
0 = No
1 = Yes
This position currently has no effect
on unit operation.
● ● ● ● ●
7 Condenser Control
0=Std Method 1
1=Std Method 2
2=Evap ABB
3=Evap MD2
4=Evap MD3
5=Evap DF
6=Not Used
7=EBM
8=INV
This Position is applicable only
when Position 1=0 or 2(RTU or
MPS).
● ● ● ●
8 Damper Type
0=None
1=Single Position 30%
2=Single Position 100%
3=Economizer Airside
4=Economizer Waterside
5=100%OA_DOAS
6=AirEcon_DOAS
7=30%_DOAS
Values 1 & 2 only apply if Position 1
= 0 (RTU) or Position 1=2 (MPS)
Value 4 only applies if Position 1 =
1 (SCU)
● ● ● ● ●
9 OA Flow Station
0=None
1=DF_015-030 (800)
2=DF_036-042 (802)
3=DF_045-075 (047)
4=DF_080-135 (077)
5=Generic Flow Station
6=Generic Flow Station w/CO
2
7=Ebtron MB
This position is only valid if: Position
1 = 0 or 2 (RTU or MPS) and
Position 8 = 3
● ● ● ● ●
10 Heating Type
0=None
1=F&BP Control
2=Staged
3=Modulated Gas, 3-1
4=Modulated Gas 20-1
5=Steam or Hot Water
6=SCR Electric
7=MPSLoGas
8=MPSHiGas
Values 3 and 4 are valid selections
only if Position 1 = 0 (RTU)
Values 7 and 8 are valid selections
only if Position 1 = 2 (MPS)
● ● ● ● ●
11 Max Heating Stages 1-8 Stages (Default = 1) ● ● ● ● ●
12, 13, 14 Max Heat Rise Three Digits (Default = 100)
This value is only valid if: Position
10=2,3,4, 6.7or8
● ● ● ● ●
15 Supply Fan Type
0=Constant Volume
1=VFD/ABB
2=VFD/DF
3=VFD/MD2
4=VFD/MD3
5=VFD/MD6
6=EBMVAV
7=EBMCAV
● ● ● ● ●
16 Return Fan Type
0=CAV
1=RF_EF VFD/ABB
2=RF_EF VFD/DF
3=RF_EF VFD/MD2
4=RF_EF VFD/MD3
5=RF_EF VFD/MD6
6=PrpEx VFD/ABB
7=PrpEx VFD/DF
8=PrpEx VFD/MD2
9=PrpEx VFD/MD3
A=PrpEx VFD/MD6
B=None
C=1StageExh
D=2StageExh
E=3StageExh
F=EBMVAV
G=EBMCAV
This position valid only when
Position 1=0 (RTU) or Position 1 =
2 (MPS).
● ● ● ●
