Daikin VRV IV-S RXTQ60TAVJU User Manual

SiUS331604E Model Names of Indoor/Outdoor Units
General Information 2
1. Model Names of Indoor/Outdoor Units
1.1 Indoor Unit
1.2 Air Treatment Equipment
Outdoor Air Processing Unit
Energy Recovery Ventilator (VAM series)
1.3 Outdoor Unit
Capacity Range 0.6 ton 0.8 ton 1 ton 1.25 ton 1.5 ton 2 ton 2.5 ton 3 ton 3.5 ton 4 ton 4.5 ton 6 ton
Power Supply,
Standard
Capacity Index 7.5 9.5 12 15 18 20 24 30 36 42 48 54 72
Ceiling Mounted Cassette
(Round Flow with Sensing) Type
FXFQ 07T 09T 12T 15T 18T — 24T 30T 36T — 48T — —
VJU
Ceiling Mounted Cassette
(Round Flow) Type
FXFQ — 09P 12P — 18P — 24P 30P 36P — 48P — —
4 Way Ceiling Mounted
Cassette (2'×2') Type
FXZQ07M09M12M15M18M————————VJU9
4-Way Blow Ceiling-Suspended Type FXUQ—————18P24P30P36P————
VJU
One Way Blow Cassette TypeFXEQ07P09P12P15P18P—24P——————
Slim Ceiling Mounted Duct Type FXDQ07M09M12M—18M—24M——————
Ceiling Mounted Duct Type
(Middle and High Static Pressure)
FXMQ 07PB 09PB 12PB 15PB 18PB — 24PB 30PB 36PB — 48PB 54PB —
Ceiling Mounted Duct Type FXMQ — — — —————————72M
Ceiling Suspended Type FXHQ — — 12M — — — 24M — 36M ————
Wall Mounted Type FXAQ 07P 09P 12P — 18P — 24P — —————
Floor Standing Type FXLQ 07M 09M 12M — 18M — 24M — —————
Concealed Floor Standing Type FXNQ07M09M12M—18M—24M——————
Vertical Air Handling Unit FXTQ — — 12PA — 18PA — 24PA 30PA 36PA 42PA 48PA 54PA —
VJ : 1 phase, 208/230 V, 60 Hz
U(VJU
) : Standard symbol
Series Model Name
Power Supply,
Standard
FXMQ 48MF 72MF VJU
Series Model Name
Power Supply,
Standard
Energy Recovery
Ventilator
VAM 300G 470G 600G 1200G VJU
VJ : 1 phase, 208/230 V, 60 Hz
U(VJU
) : Standard symbol
Capacity Range 3 ton 4 ton 5 ton
Power Supply,
Standard
Capacity Index 36 48 57
Heat Pump RXTQ 36TA 48TA 60TA VJU
VJ : 1 phase, 208/230 V, 60 Hz
U(VJU) : Standard symbol

Daikin VRV IV-S RXTQ60TAVJU Specifications

General

Category	Heat Pump
Model	RXTQ60TAVJU
Energy Efficiency Ratio (EER)	3.48
Refrigerant	R410A
Power Supply	50 Hz
Operating Temperature (Heating)	-15 to 20 °C
