Daikin VRV IV-S RXTQ60TAVJU User Manual

SiUS331604E Functional Parts Layout
Refrigerant Circuit 14
2.2 RXTQ48TAVJU
Front view
Low pressure sensor
(S1NPL)
Four way valve
(Y1S)
Thermistor (Discharge pipe)
(R2T)
High pressure switch
(S1PH)
Crankcase heater
Compressor
(M1C)
Four way valve coil
(Y1S)
Thermistor (Suction pipe 2)
(R5T)
Solenoid valve (Unload circuit) coil
(Y3S)
Thermistor (Liquid)
(R7T)
High pressure sensor
(S1NPH)
Electronic expansion valve/coil (Main)
(Y1E)

Daikin VRV IV-S RXTQ60TAVJU Specifications

General

Category	Heat Pump
Model	RXTQ60TAVJU
Energy Efficiency Ratio (EER)	3.48
Refrigerant	R410A
Power Supply	50 Hz
Operating Temperature (Heating)	-15 to 20 °C
