Refrigerant Circuit SiUS331604E
11 Refrigerant Circuit
1.3 RXTQ60TAVJU
No. in
piping
diagram
Symbol Name Function
(1) M1C Inverter compressor
Inverter compressor is operated on frequencies between 36Hz and 195Hz by using the
inverter.
(2)
M1F
M2F
Inverter fan
Because the system is of an air heat exchange type, the fan is operated at 8-step rotation
speed by using the inverter.
(3) Y1E
Electronic expansion valve
(Main)
While in heating operation, PI control is applied to keep the outlet superheated degree of
air heat exchanger constant.
(4) Y3E
Electronic expansion valve
(Subcooling)
Pl control is applied to keep the outlet superheated degree of subcooling heat exchanger
constant.
(5) Y1S Four way valve Used to switch the operation mode between cooling and heating.
(6) S1NPH High pressure sensor Used to detect high pressure.
(7) S1NPL Low pressure sensor Used to detect low pressure.
(8) S1PH High pressure switch
In order to prevent the increase of high pressure when an error occurs, this switch is
activated at high pressure of 4.0 MPa (580 psi) or more to stop the compressor operation.
(9) — Fusible plug
In order to prevent the increase of pressure when abnormal heating is caused by fire or
others, the fusible part of the plug is molten at a temperature of 70 ~ 75°C (158 ~ 167°F) to
release the pressure into the atmosphere.
(10) —
Pressure regulating valve 1
(Receiver to discharge pipe)
This valve opens at a pressure of 4.0 MPa (580 psi) or more for prevention of pressure
increase, thus resulting in no damage of functional parts due to the increase of pressure in
transportation or storage.
(11) R1T Thermistor (Outdoor air) Used to detect outdoor air temperature, correct discharge pipe temperature, and others.
(12) R2T Thermistor (Discharge pipe)
Used to detect discharge pipe temperature, make the temperature protection control of
compressor, and others.
(13) R3T Thermistor (Suction pipe 1)
Used to detect suction pipe temperature, keep the suction superheated degree constant in
heating operation, and others.
(14) R4T
Thermistor (Heat exchanger
deicer)
Used to detect liquid pipe temperature of air heat exchanger, determine defrost operation,
and others.
(15) R5T Thermistor (Suction pipe 2) Used to the calculation of an internal temperature of compressor etc.
(16) R6T
Thermistor (Subcooling heat
exchanger gas pipe)
Used to detect gas pipe temperature on the evaporation side of subcooling heat
exchanger, keep the superheated degree at the subcooling heat exchanger constant, and
others.
(17) R7T Thermistor (Liquid pipe) Used to detect refrigerant overcharge in check operation, and others.
(18)
FIN
TH
Thermistor (Radiation fin)
• Used for outdoor unit fan speed control.
• Used for inverter radiation fin temperature control.
• Used for pressure difference control.
To Next Page
