SiUS331604E Names and Functions
Remote Controller 20
2. Names and Functions
2.1 BRC1E73
Functions other than basic operation items (i.e., On/Off, Operation Mode, Fan Speed, and Setpoint) are
set from the menu screen.
Note:
Do not install the remote controller in places exposed to direct sunlight, the LCD will be damaged.
Do not pull or twist the remote controller cord, the remote controller may be damaged.
Do not use objects with sharp ends to press the buttons on the remote controller damage may result.
1. Operation mode selector button
Press this button to select the operation mode of your preference.
∗ Available modes vary with the indoor unit model.
2. Fan speed control button
Press this button to select the fan speed of your preference.
∗ Available fan speeds vary with the indoor unit model.
3. Menu/OK button
Used to enter the main menu.
Used to enter the selected item.
3. Menu/OK button
8. On/Off button
10. Cancel button
9. Operation lamp
11. LCD (with backlight)
4. Up button
5. Down button
6. Right button
7. Left button
1. Operation mode
selector button
2. Fan speed control
button
To Next Page
