DAKEWE 6250 - Blade Holder Installation; Glass Door Installation

Dakewe(Shenzhen)Medical Equipment Co,. Ltd 21 V4.1
4.4.6 Blade Holder Installation
As shown in the figure, insert it into the rail on the bottom plate of the freezing chamber
compartment’s blade holder in the direction of the blade holder’s open dovetail slot (Figure
11-2)
Slide to the appropriate position, then rotate the handle to lock the blade holder.
4.4.7 Glass Door Installation
Open slot
Blade holder front and rear movement locking handle
Blade holder mounting plate
Figure 11 The procedure of blade holder installation
Figure 12 The procedure of glass door installation
Conductive sheet
Conductive electrode
