Dakewe(Shenzhen)Medical Equipment Co,. Ltd 33 V4.1
5.6.4 Anti-roll Plate Adjustment
1. Microtome knife blade 2. Anti-roll plate edge
3. Blade and anti-roll plate parallel adjustment screw
Insert the blade and lock the blade locking handle.
Lock both anti-roll plate locking knobs.
Use a hex wrench to loosen the parallel adjustment screw for blade and anti-roll plate.
Adjust the parallel between the blade edge and the anti-roll plate edge.
Relock and tighten the blade and anti-roll plate parallel adjustment screw.
Precautions:
1: Protect the area where the anti-roll plate is in contact with the tissue piece without any
damage.
2: When you feel that the quality of the cut tissue is not high, you should check the blade and
the anti-roll plate for any tissue fragments, grease and other foreign matter.
3: Avoid touching the edge of the anti-roll plate with your hand or other hot objects, otherwise
the tissue pieces will stick as the temperature rises.
5.6.5 Microtome Blade Angle Adjustment
Use a hex wrench to loosen (counterclockwise rotation) the blade slicing angle locking screw,
then manually push the blade holder edge along the arc angle of the blade holder to adjust the
angle. The adjustable angle range is 0-10°, then fix the blade slicing angle locking screw. If the
slicing effect is not good, the angle can be tested by 1° until it is adjusted well, but the angle
cannot be changed more than 10°.
