110  Technical Specifications Genie HM-HC Series-GigE Vision Camera
Trigger
Debounce
IN
3.3V
Genie
TTL External Signal Example
4.7K
Fairchild
HMHA281R
.01µf
680
IN+
IN-
Hirose 12
connector
V+
Event
Signal
Buffer
driver
example
74HC244
Trigger
Debounce
IN
3.3V
Genie
RS-422 External Signal Example
4.7K
Fairchild
HMHA281R
.01µf
680
IN+
IN-
Hirose 12
connector
Event
Signal
Buffer
driver
example
SN75179B
Trigger
Debounce
IN
3.3V
Genie
24 Volt External Signal Example
4.7K
Fairchild
HMHA281R
.01µf
680
IN+
IN-
Hirose 12
connector
680 1/2W
Event
Signal
