50 Operational Reference Genie HM-HC Series-GigE Vision Camera
Exposure Controls via Sapera LT or GigE Vision Compliant
Applications
Sap era
Genie Sapera parameters for Exposure Control:
FrameRate = 0.1 Hz up to max. frame rate supported by sensor in current mode of operation.
Only available with Trigger disabled.
ExposureMode = {Programmable = 1, Pulse Controlled = 2}
ExposureTime = Exposure duration in µs
In CamExpert, these parameters are available under “Sensor” tab.
See "Accessing Features with Sapera++ LT" on page 76.
XML features for Exposure Control:
ExposureMode = {Off = 0, Timed = 1, TriggerWidth = 2, TriggerControlled = 3,
ResetContinuous = 4}
ExposureTimeRaw = Exposure duration in µs
ExposureDelay = The delay from active trigger edge to start of exposure.
AcquisitionFrameRateRaw = Controls the desired frame rate of the camera in mHz (0.001 Hz).
Only available when trigger is disabled.
AcquisitionFrameRateAbs = Controls the desired frame rate of the camera in Hz. Only
available when the frame trigger is disabled.
AcquisitionFrameCount = Number of frames to be acquired in MultiFrame acquisition mode
AcquisitionMode = {Continuous = 0, SingleFrame = 1, MultiFrame = 2}
AcquisitionArm = Verify all parameters for image capture and prepares for AcquistionStart
AcquisitionStart = Start image capture using currently selected acquisition mode
AcquisitionStop = Stop the acquisition at the end of the current exposure
AcquisitionAbort = Abort an acquisition immediately without completing the current frame
TLParamsLocked = Flag to indicate if features are locked during acquisition.
